Standard features

• Max Cutting window: 31" x 60" table or 31" x 80" table
• Max Cutting speed: 23.2 ips
• Acceleration: 1G's
• Maximum Material Width: 33"
• Overall Dimensions: 43" x 78" x 41" or 43" x 98" x 41"
• Maximum Material Thickness 0.150"
• Cutting Force: 30-500 grams in 2 grams increment
• Mechanical Accuracy: 0.001"
• Configuration: Closed Loop Digital Servo System
• Repeatability: 0.004"
• User Control: 20 x 4 LCD with back light and 9 hot keys
• Interface: USB 2.0
• Buffer: 2M with Auto Data Compression
• Vacuum hold down with 1/2HP vacuum pump

Power Requirement

• Power input: 10A @ 115V or 5A @ 230V

Computer/Software requirement

• Software Accuracy: 0.0001 in X and 0.0001 in Y
• Software Language Driver: Compatible with all graphics software using HPGL format, including CorelDRAW and MemorialDESIGNER
