Standard features
- Max Cutting window: 31" x 60" table
- Max Cutting speed: 23.2 ips
- Acceleration: 1G's
- Maximum Material Width: 33"
- Overall Dimensions: 43" x 78" x 41"
- Maximum Material Thickness 0.150"
- Cutting Force: 30-500 grams in 2 grams increment
- Mechanical Accuracy: 0.001"
- Configuration: Closed Loop Digital Servo System
- Repeatability: 0.004"
- User Control: 20 x 4 LCD with back light and 9 hot keys
- Interface: USB 2.0
- Buffer: 2M with Auto Data Compression
- Vacuum hold down with 1/2HP vacuum pump
Power Requirement
- Power input: 10A @ 115V or 5A @ 230V
